COOLING TOWERS / Crossflow /
MHD Series
The MHD serie is side-in and side-out type, which is an economical and practical cross flow cooling tower,  especially suitable for operating environments with various restrictions in commercial buildings, and can be installed outdoors and indoors.
The MHD serie is side-in and side-out type, which is an economical and practical cross flow cooling tower, especially suitable for operating environments with various restrictions in commercial buildings, and can be installed outdoors and indoors.
组装
Assembly
Factory assembled
配置. png
Configuration
Cross Flow Induced Draft
水流量
Capacity
Single cell:
45-250m³/h
认证
Certification
ASHRAE-90.1-2019
GB/T 7190
CTI STD-201
MHD-2
直传风机
运输图
The MHD serial is a side-in and side-out type, which is an economical and practical cross flow cooling tower, especially suitable for operating environments with various restrictions in commercial buildings, and can be installed outdoors and indoors. The whole series has 8 towers, a total of 48 models, and per unit operating water flow from 45m³/h to 351m³/h, which can meet a wide range of working conditions.
The shell and frame are made of galvanized steel plate in Pohang, South Korea, to ensure that the overall strength of the cooling tower is sufficient to meet the requirements of most operating environments, and it is approved by computer simulation damage analysis
Compliant with the following international standards and certification:
● ASHRAE 90.1
● GB/T 7190
● CTI STD-201
●  Capacity range: 45-250m³/h
●  HDGS construction
● Direct drive, belt or gear drive is available
● Factory assembled

● SS304/SS316 Casing & Structure
● High temperature PP infill
● Belt Drives
● Filtration system cleans the basin
● PVC infill




MHD-CN.pdf
MHD-EN.pdf
CTI Certification
MHD Selection Table.pdf
